Product Description
This listing includes a top quality AlNiCo magnet which is made of AlNiCo 5 material. This magnet is 6mm square and 12mm long and magnetized through 6mm so the N and S poles are on the 12mm x 6mm surfaces. This magnet has a holding of 0.6kg
AlNiCo magnets have an extrodinary temperature stability than the other types of magnets so it is mostly used in the industries like high temperature tooling or oil fields where high temperature is present.
Generally speaking, AlNiCo magnets are more fragile than neodymium magnets. AlNoCo magnets have a better machinability so it can be made with higher precision. It also exhibites a better conductivity than the other types of magnets. There is no coating for this magnet. The following is the magnetic characteristics of this magnet.
- Material: AlNiCo class 5
- Magnetic Characteristics: Br: 1,200mT, Hcb: 48kA/m, BH: 37KJ/m³
- Holding Power:
- Pole Orientation: Magnetized through 6mm, i.e. the north and south poles are on the 12mm x 6mm surfaces
- Tolerances: +/- 0.1mm
- Maximum Normal Operating Temperature: 550 degree C or 1,022 degree F (5% loss of the magnetism at this temperature)
Magnetop Magnetics provides the best quality AlNiCo magnets for Australian industries. All of our products are made via state of the art technology. All the magnets are made of highly purified raw material under ISO 9001 quality systems.
Should you need different grades or dimensions of AlNico magnets, we may custom make for you per your requirements.
